Form 4BL Premium Medical Package
Unmatched Uptime and Capacity for 24/7 Healthcare Operations
The Form 4BL Premium Medical Package is designed for organizations where large-format 3D printing is a mission-critical component of the clinical or production workflow. This configuration effectively doubles your post-processing capacity and eliminates the need for manual resin management, allowing your team to move from patient scan to finished, validated medical device faster than ever before.
Why Choose the Formlabs Form 4BL Complete Package?
- Parallel Processing Workflow: Includes two Form Wash L units. This redundant setup allows your team to initiate the cleaning cycle for one batch of anatomical models or dental appliances while the printer is already running its next print, eliminating the single greatest bottleneck in high-volume labs.
- Bulk Resin Efficiency: Features two Resin Pumping Systems. By automatically dispensing resin from 5L bulk containers, you eliminate the constant manual cartridge swaps, significantly reducing labor and lowering your per-part material costs.
- Open Material Freedom: Includes Open Material Mode (OMM), providing the flexibility to utilize specialized 405nm materials for research or unique clinical applications beyond the standard biocompatible library.
-
Maximum Service Continuity: Includes a 5 Year Medical Professional Service Plan (MSP). This ensures your facility is protected by priority technical support from certified medical experts, live training, and expedited "Hot Swap" hardware replacements to ensure near-zero downtime.
What's in the Box?
| Included Component | Purpose |
| Form 4BL 3D Printer | Large-format medical print engine. |
| 2x Form Wash L (2nd Gen) | Parallel cleaning capacity for large-format throughput. |
| Form Cure L (2nd Gen) | Uniform UV/heat chamber for medical-grade curing. |
| 2x Form 4L Resin Tank | Long-lasting tank (rated for 75,000+ layers). |
| 2x Form 4L Mixer | Ensures consistent material quality for large parts. |
| 2x Resin Pumping System | Automates 5L bulk material delivery |
| 2x Build Platform Flex L | Large-format surface for tool-free removal. |
| Finishing Tools Set | Professional set for clinical refinement of parts. |
| Open Material Mode | License for specialized R&D materials. |
| Medical Service Plan | Up to 5 years of priority support and hardware coverage. |
Tech Specs
|
Specification |
Details |
| Technology | Low Force Display (LFD)/mSLA |
| Build Volume | 353 x 196 x 350 mm (24.2 L) |
| XY Resolution | 46 microns |
| Layer Thickness | 25-200 microns |
| Max Print Speed | 80 mm/h |
| Resin System | Automated Dual-Cartridge System |
| Printer Dimensions | 66.4 x 52.8 x 79.4 cm |
| Medical Compatibility | Validated for BioMed and Dental Resins |
FAQ
Why Choose the Premium Package Over the Complete Package?
For high-volume dental labs or hospitals, time-to-delivery is critical. The Premium Package's dual wash stations and automated resin pumping are designed for facilities that run multiple large prints daily. It removes the need for technicians to manually manage resin or wait for wash cycles to finish before starting a new build, maximizing your daily throughput.
How Does the Resin Pumping System Help a Medical Lab?
Beyond saving time, the pumping system allows you to use 5L bulk containers, which reduces the cost of resin per liter and significantly decreases the amount of plastic waste generated by standard 1L cartridges.
Is the Medical Service Plan Really Necessary?
In a clinical or production environment, unplanned downtime can disrupt patient care or surgical planning. The MSP provides "Hot Swap" hardware replacement, meaning if your printer encounters an issue, Formlabs will ship you a replacement unit immediately to keep your production line active while the issue is resolved.
